Honda Accord: Playing AM/FM Radio

• Preset Memory
To store a station:
1. Tune to the selected station.

2. Press
to switch to the
Audio menu screen.
3. Rotate
to select Save Preset,
then press
.
4. Rotate
to select the preset
number you want to store that station, then
press
.

2. Select More.
3. Select Save Preset.
4. Select the preset number you want to store that station.
The ST indicator appears on the display indicating stereo FM broadcasts.
Stereo reproduction in AM is not available.
Switching the Audio Mode Press the SOURCE button on the steering wheel.
You can also switch the mode by pressing
and
selecting Change Source on the Audio menu
screen.
You can store 6 AM stations and 12 FM stations into the preset memory.
• Radio Data System (RDS)
Provides text data information related to your selected RDS-capable FM station.
• To find an RDS station from Station List
1. Press
to switch to the
Audio menu screen while listening to an FM station.
2. Rotate
to select Station List,
then press
.
3. Rotate
to select the station,
then press
.
• Manual update
Updates your available station list at any time.
1. Press
to switch to the
Audio menu screen while listening to an FM station.
2. Rotate
to select Station List,
then press
.
3. Rotate
to select UPDATE LIST,
then press
.
When you select an RDS-capable FM station, the RDS automatically turns on, and the frequency display changes to the station name. However, when the signals of that station become weak, the display changes from the station name to the frequency.
• Radio text
Displays the radio text information of the selected RDS station.
1. Press
to switch to the Audio
menu screen.
2. Rotate
to select Radio Text,
then press
.
• Scan
Samples each of the strongest stations on the selected band for 10 seconds.

1. Press
to switch to the
Audio menu screen.
2. Rotate
to select Scan,
then press
.
To turn off scan, press
to select
Cancel Scan, or press the BACK button.

1. Select More.
2. Select Scan.
To turn off scan, select Cancel Scan.
The text indicator comes on when you received a text message. The indicator stays on until you read the message.
Display Setup
You can change the brightness or color theme of the audio/information screen.
• Changing the Screen Brightness
1. Press and hold the DISP button to go to the
Settings screen.
2. Rotate to s ...
Playing XM® Radio
• To Play the XM® Radio
1. Select the XM® mode.
2. Press to switch to the
Audio menu screen.
3. Rotate to select XM Tune Mode,
then press .
4. Rotate to select Channel Mode
or C ...
