Honda Accord: The Passenger’s Front Airbag Can Pose Serious Risks
Front airbags have been designed to help protect adults in a moderate to severe frontal collision. To do this, the passenger’s front airbag is quite large, and it can inflate with enough force to cause very serious injuries.
Even though your vehicle has an advanced front airbag system that automatically turns the passenger’s front airbag off under certain circumstances, please follow these guidelines:
Never put a rear-facing child seat in the front seat of a vehicle equipped with a passenger’s front airbag. If the airbag inflates, it can hit the back of the child seat with enough force to kill or very seriously injure an infant.
Placing a forward-facing child seat in the front seat of a vehicle equipped with a passenger’s front airbag can be hazardous. If the vehicle seat is too far forward, or the child’s head is thrown forward during a collision, an inflating front airbag can strike the child with enough force to kill or very seriously injure a small child.
Children who have outgrown child seats are also at risk of being injured or killed by an inflating passenger’s front airbag.
Whenever possible, larger children should sit in the back seat, on a booster seat if needed, and be properly restrained with a seat belt (see for important information about protecting larger children).
To remind you of the passenger’s front airbag hazards, and that children must be properly restrained in a back seat, your vehicle has warning labels on the dashboard (U.S. models) and on the front visors.
Please read and follow the instructions on these labels.
Exploded View-Clutch Housing 1.DIFFERENTIAL ASSEMBLY 2.SHIFT FORK ASSEMBLY 3.6 mm FLANGE BOLT 13 N-m (1.3 kgf-m, 9.4 Ibf-ft) 4.BEARING SET PLATE 5.COUNTERSHAFT ASSEMBLY 6.NEEDLE BEARING 7.OI ...
Oil Pump Chain inspection
1. Remove the oil pan (see page 7-11). 2. Measure the oil pump chain auto-tensioner rod length. If the length is over the service limit, replace the oil pump chain (see page 8-25). Oil Pump Chai ...
Washer Reservoir Replacement
1. Remove the right inner fender (see page 20-290). 2. Disconnect the 2P connector(s) (A) from the washer motor (B) and the washer fluid level switch (Canada models). Washer Reservoir Capacity: ...
