Circuit Diagram
DRIVER'S UNDER-DASH
FUSE/RELAY BOX CONNECTOR N (16P)
Wire side of female terminals
DRIVER'S UNDER-DASH
FUSE/RELAY BOX CONNECTOR P (20P)
Wire side of female terminals
GAUGE CONTROL MODULE 3 ...
Component Location Index
4-door
2-door
...
Electrical Compass Unit Input
Test
1. Remove the rear shelf (see page 20-128).
2. Loosen the bolts (A), then pull out the electrical compass unit bracket (B).
3. Disconnect the 6P connector (C) and remove the mounting bolt ( D ) ...
