Honda Accord: Under-hood Emission Control Label
Emission Group Identification
Example:
08 Model
COMFORMS TO REGULATIONS: 2008 MY
Test Group and Evaporative Family
Test Group:
Model Year
8: '08
9: '09
A: "10
Manufacturer Subcode
HNX: HONDA
Family Type
V: LDV
Displacement Group
Sequence Characters
TKR: '08 model (ULEV)
EMC: '08 model (SULEV/PZEV)
YB3: '09 model (ULEV)
TC3: '09 model (SULEV/PZEV)
MB3: '10 model (ULEV)
KC3: '10 model (SULEV/PZEV)
- Evaporative Family:
Model Year
8: '08
9: '09
A: "10
Manufacturer Subcode
HNX: HONDA
Family Type
R: Refueling
Canister Working Capacity Group
Sequence Characters
BCA, BBA: '08 model
VEA, VZA: '09-10 models
