Center Pocket Removal/Installation
Without Navigation System NOTE; - Take care not to scratch the dashboard or the related parts. - A/T is shown; M/T is similar. 1. Remove the center console panel (see page 20-157). 2. A/T: ...

MICU Input Test
NOTE: # Before t e s t i n g , t r o u b l e s h o o t the m u l t i p l e x i n t e g r a t e d control unit first, using B-CAN System D i a g n o s i s Test Mode A (see page 22-134). • B ...

Motor Test
1. Remove the front seat back panel, and seat-back cover/pad. • 4-door (see page 20-221) • 2-door (see page 20-213) 2. Disconnect the 2P connector (A) from the lumbar support motor (B ...
